DRV8825 A4988 3D Printer 42 Stepper Motor Driver Expansion Board Control Shield Module DIY Kit H8WD
Features:
brand new and high quality
With On-board DIP switch, you can easily adjust the drive segments Terminal power connector for easy connection drive power.
for 12 / 24V drive scheme
Suitable for 42 stepper motor drive, 3D printers and DIY.
Pitch: 1400 x 1400mil (35.56 x 35.56mm) Logic voltage: 5V Input voltage: 12-30V
Applicable module: A4988, DRV8825
Please note the direction when installing the drive module, otherwise it will burn module
Specifications:
Name: 4988/8825 Stepper Motor Drive Module Expansion Board
Size: approx 42x42x15mm/1.65×1.65×0.59in
Fixing: 3mm
Hole Spacing: 1400x1400mil (35.56×35.56mm)
Logic Voltage: 5V
Input Voltage: 12-30V
port: Digital
Applicable Modules: A4988, DRV8825
Package Includes:
1 PC x Expansion Board
Note:
This product is only an expansion board, does not include 4988/8825 driver module
Please note the direction when installing the drive module, otherwise it will burn module.
Due to the differences of camera equipment, light intensity and display screens, the color of the item may be slightly different from that shown in the pictures.
Please allow 0-2cm size difference due to manual measurement.
