Specification
Appearance size:93*87mm
Microprocessor: GD32F205VCT6
Power Input: DC5V
SD card logic voltage:3.3V/5V
Weight: 109g
perfectly replace:perfectly replace the original LCD screen of Ender3 printer.
Main control chip:ARM Cortex-M3 Series GD32F205VCT6 Master Controller with 32-bit Main Frequency of 120MHz
Selected connect wire according to the firmware:Please connect different wire according to the firmware you burned.
-
When using serial touch screen mode,it connects with TFT or AUX-1 on the motherboard through RS232,which has touch function
-
When using class 12864 LCD mode,it connects with EXP3 of the motherboard,which has no touch function
-
When using class 12864 LCD mode,it connects with EXP1 and EXP2 of the motherboard,which has no touch function
Exquisite appearance:Better lighting effect after optimization
TWO Pinting methods:Serial port screen mode supports two printing modes: SD card and U disk
WIFl port:Reserve WIFl port,and WIFl function is realized by external WIFl module
Expand the port for users to DIY:2 sets of UART serial port extension ports are reserved for DIY use.
